Part NO. |
Thread E |
Hose Bore - DN |
Hose Bore - Dash |
Tube O.D |
O Ring |
A |
C |
S2 |
|
20511-14-04 |
M16X1.5 |
6 |
4 |
6 |
004.5X1.5 |
29 |
1.5 |
19 |
|
20511-16-04 |
M16X1.5 |
6 |
4 |
8 |
006.5X1.5 |
29 |
1.5 |
22 |
|
20511-16-05 |
M16X1.5 |
8 |
5 |
8 |
006.5X1.5 |
29 |
1.5 |
22 |
|
20511-18-04T |
M18X1.5 |
6 |
4 |
10 |
008.0X1.5 |
25.5 |
1.5 |
22 |
|
20511-18-06 |
M18X1.5 |
10 |
6 |
10 |
008.0X1.5 |
29 |
2 |
24 |
|
20511-20-06T |
M20X1.5 |
10 |
6 |
12 |
010.0X1.5 |
26.5 |
2.5 |
24 |
|
20511-20-08 |
M20X1.5 |
12 |
8 |
12 |
010.0X1.5 |
31.5 |
2.5 |
27 |
|
20511-22-06T |
M22X1.5 |
10 |
6 |
14 |
011.0X2.0 |
26.5 |
3 |
27 |
|
20511-22-08 |
M22X1.5 |
12 |
8 |
14 |
011.0X2.0 |
31.5 |
2.5 |
27 |
|
20511-24-06T |
M24X1.5 |
10 |
6 |
16 |
013.0X2.0 |
27 |
3 |
30 |
|
20511-24-08T |
M24X1.5 |
12 |
8 |
16 |
013.0X2.0 |
27.5 |
3 |
30 |
|
20511-30-10T |
M30X2 |
16 |
10 |
20 |
016.3X2.4 |
33 |
2.5 |
36 |
|
20511-30-12 |
M30X2 |
20 |
12 |
20 |
016.3X2.4 |
39 |
3 |
36 |
|
20511-36-12T |
M36X2 |
20 |
12 |
25 |
020.3X2.4 |
35 |
3.2 |
46 |
|
20511-36-14T |
M36X2 |
22 |
14 |
25 |
020.3X2.4 |
34 |
3.2 |
46 |
|
20511-42-12T |
M42X2 |
20 |
12 |
30 |
025.3X2.4 |
37.5 |
3.9 |
50 |
|
20511-42-16T |
M42X2 |
25 |
16 |
30 |
025.3X2.4 |
38.5 |
3.9 |
50 |
|
20511-52-20T |
M52X2 |
32 |
20 |
38 |
033.3X2.4 |
41.5 |
4.5 |
60 |
|
20511-52-24T |
M52X2 |
40 |
24 |
38 |
033.3X2.4 |
41.5 |
4.5 |
60 |
|
Note: I.For use with braided hoses. 2.If use with spiral hoses, hose fitting series number is 20512-XX-XX |
||||||||
| Forma | Straight |
|---|---|
| Tipo di montaggio | Cone |
| Tipo di filettatura | Female |
| Connection Type | Metric |
