Part NO. |
Thread E |
Hose Bore DN |
Hose Bore Dash |
Tube O.D |
A |
C |
S2 |
|
20411-12-04 |
M12X1.5 |
6 |
4 |
6 |
26 |
1 |
17 |
|
20411-14-04 |
M14X1.5 |
6 |
4 |
8 |
27.5 |
2 |
19 |
|
20411-14-06 |
M14X1.5 |
10 |
6 |
8 |
27.5 |
2 |
19 |
|
20411-16-04 |
M16X1.5 |
6 |
4 |
10 |
28 |
2 |
22 |
|
20411-16-05 |
M16X1.5 |
8 |
5 |
10 |
28 |
2 |
22 |
|
20411-16-06 |
M16X1.5 |
10 |
6 |
10 |
28 |
2 |
22 |
|
20411-18-05T |
M18X1.5 |
8 |
5 |
12 |
24.5 |
1.5 |
22 |
|
20411-18-06 |
M18X1.5 |
10 |
6 |
12 |
29 |
2.5 |
24 |
|
20411-18-08 |
M18X1.5 |
12 |
8 |
12 |
29.5 |
2.5 |
24 |
|
20411-22-05T |
M22X1.5 |
8 |
5 |
15 |
26.5 |
3 |
27 |
|
20411-22-06T |
M22X1.5 |
10 |
6 |
15 |
26.5 |
3 |
27 |
|
20411-22-08 |
M22X1.5 |
12 |
8 |
15 |
32 |
2.5 |
27 |
|
20411-26-10 |
M26X1.5 |
16 |
10 |
18 |
34.5 |
2.5 |
32 |
|
20411-26-12 |
M26X1.5 |
20 |
12 |
18 |
35 |
2.5 |
32 |
|
20411-27-10T |
M27X1.5 |
16 |
10 |
18 |
35 |
2.1 |
32 |
|
20411-27-12 |
M27X1.5 |
20 |
12 |
18 |
35 |
2.5 |
32 |
|
20411-30-10T |
M30X2 |
16 |
10 |
22 |
31 |
3.8 |
36 |
|
20411-30-12 |
M30X2 |
20 |
12 |
22 |
39 |
4 |
36 |
|
20411-36-12T |
M36X2 |
20 |
12 |
28 |
33 |
4.5 |
46 |
|
20411-36-14T |
M36X2 |
22 |
14 |
28 |
33 |
4.5 |
46 |
|
20411-45-16T |
M45X2 |
25 |
16 |
35 |
37 |
4 |
55 |
|
20411-45-20T |
M45X2 |
32 |
20 |
35 |
37.5 |
4 |
55 |
|
20411-52-20T |
M52X2 |
32 |
20 |
42 |
38.5 |
4 |
60 |
|
20411-52-24T |
M52X2 |
40 |
24 |
42 |
38.5 |
4 |
60 |
|
Note: 1.For use with braided hoses. 2.lf use with spiral hoses, hose fitting series number is 20412-xx-xx |
|||||||
| Shape | Straight |
|---|---|
| Fitting Type | Cone |
| Thread Type | Female |
| Connection Type | Metric |
| Brand | SAFECAN |
