Part NO. |
E |
Tube O.D. |
A |
D |
S2 |
Working Pressure bar |
|
2WE-06-12 |
M12X1.25 |
6 |
8 |
6 |
14 |
PN630 |
|
2WE-08-14 |
M14X1.5 |
8 |
8.5 |
8 |
17 |
PN630 |
|
2WE-10-16 |
M16X1.5 |
10 |
8.5 |
10 |
19 |
PN630 |
|
2WE-12-18 |
M18X1.5 |
12 |
8.5 |
12 |
22 |
PN630 |
|
2WE-14-22 |
M22X1.5 |
14 |
10 |
14 |
27 |
PN630 |
|
2WE-18-27 |
M27X1.5 |
18 |
10 |
18 |
32 |
PN400 |
|
2WE-22-30 |
M30X1.5 |
22 |
11 |
22 |
36 |
PN400 |
|
2WE-28-36 |
M36X2 |
28 |
13 |
28 |
41 |
PN400 |
|
2WE-30-39 |
M39X2 |
30 |
13 |
30 |
46 |
PN250 |
|
2WE-34-42 |
M42X2 |
34 |
15 |
34 |
50 |
PN250 |
|
2WE-38-45 |
M45X2 |
38 |
15 |
38 |
55 |
PN250 |
|
2WE-42-52 |
M52X2 |
42 |
17 |
42 |
60 |
PN250 |
|
2WE-50-60 |
M60X2 |
50 |
20 |
50 |
70 |
PN250 |
|
2WE-52-64 |
M64X2 |
52 |
23 |
52 |
75 |
PN250 |
|
1.PN = Nominal Pressure |
||||||
| Forme | Straight |
|---|---|
| Type de fil | Female |
| Connection Type | Metric, Weld |
| Brand | SAFECAN |
| Type de montage | Face Seal, Weld |
