Part NO. |
Thread E |
Hose Bore - DN |
Hose Bore - Dash |
Tube O.D |
O Ring |
A |
C |
H |
S2 |
|
20541-14-04 |
M16X1.5 |
6 |
4 |
6 |
004.5X1.5 |
43.4 |
1.5 |
21.3 |
19 |
|
20541-16-04 |
M16X1.5 |
6 |
4 |
8 |
006.5X1.5 |
44.4 |
1.5 |
22.3 |
22 |
|
20541-16-05 |
M16X1.5 |
8 |
5 |
8 |
006.5X1.5 |
46.6 |
1.5 |
23.2 |
22 |
|
20541-18-04T |
M18X1.5 |
6 |
4 |
10 |
008.0X1.5 |
43.7 |
1.5 |
21.6 |
22 |
|
20541-18-06 |
M18X1.5 |
10 |
6 |
10 |
008.0X1.5 |
48.1 |
2 |
23.9 |
24 |
|
20541-20-06T |
M20X1.5 |
10 |
6 |
12 |
010.0X1.5 |
47.8 |
2.5 |
23.5 |
24 |
|
20541-20-08 |
M20X1.5 |
12 |
8 |
12 |
010.0X1.5 |
68.1 |
2.5 |
33.2 |
27 |
|
20541-22-06T |
M22X1.5 |
10 |
6 |
14 |
011.0X2.0 |
48.1 |
3 |
23.9 |
27 |
|
20541-22-08 |
M22X1.5 |
12 |
8 |
14 |
011.0X2.0 |
68.1 |
2.5 |
33.2 |
27 |
|
20541-24-08T |
M24X1.5 |
12 |
8 |
16 |
013.0X2.0 |
62.5 |
3 |
27.5 |
30 |
|
20541-30-10T |
M30X2 |
16 |
10 |
20 |
016.3X2.4 |
73.5 |
2.5 |
29.2 |
36 |
|
20541-30-12 |
M30X2 |
20 |
12 |
20 |
016.3X2.4 |
77.2 |
3 |
30.3 |
36 |
|
20541-36-12T |
M36X2 |
20 |
12 |
25 |
020.3X2.4 |
81.1 |
3.2 |
33 |
46 |
|
20541-36-14T |
M36X2 |
22 |
14 |
25 |
020.3X2.4 |
82.8 |
3.2 |
32.5 |
46 |
|
20541-42-16T |
M42X2 |
25 |
16 |
30 |
025.3X2.4 |
90.6 |
3.9 |
35.1 |
50 |
|
20541-52-20T |
M52X2 |
32 |
20 |
38 |
033.3X2.4 |
101.7 |
4.5 |
39.4 |
60 |
|
20541-52-24T |
M52X2 |
40 |
24 |
38 |
033.3X2.4 |
114.1 |
4.5 |
43.4 |
60 |
|
Note: I.For use with braided hoses. 2.If use with spiral hoses, hose fitting series number is 20542-XX-XX。 |
|||||||||
| Форма | Elbow |
|---|---|
| Тип крепления | Cone |
| Тип резьбы | Female |
| Connection Type | Metric |
